Fluke 83V Digital Multimeter 3947847

Product Code: FLU83-V

Price
£425.00 ex. VAT £510.00 inc. VAT

Available In 3-7 Days


Add To Favourites
Detailed Description

The Fluke 83V industrial digital multimeter is designed to help identify complex signal problems fast. The 3-3/4 digits digital multimeter features true rms readings which will give you accurate results without the complications. The 83V digital handheld multimeter features the accuracy and resolution to troubleshooting that industrial electricians around the world trust from the control room to the plant floor as well as electro -mechanical equipment in noisy, industrial, high energy environments and high altitude locations. The Fluke 83V digital multimeter also comes with a larger display screen with a bright, two level back light allowing you to view the analogue bar graphs and measurements in a dim working environment.

Key Features:

  • Accurate measurements of noisy pulse-width modulated AC voltage at the VSD and the motor terminals
  • Accurate frequency measurements on VSD
  • Built-in thermometer
  • Peak Min Max mode captures intermittent as fast as 250 μs
  • Easy-to-read large digit display with bright, two-level backlight
  • CAT III 1000V, CAT IV 600V safety rated
  • Lifetime warranty

The 83-V Comes Supplied With:

  • TL75 test leads
  • AC175 alligator clips
  • Yellow holster
  • 9V battery
  • Temperature probe
  • User manual
  • Operators guide
Multimeter Type Handheld
Absolute Maximum DC Current Measurement 10A dc
Absolute Maximum AC Current Measurement 10A ac
Absolute Maximum DC Voltage Measurement 1000V dc
Absolute Maximum Resistance Measurement 50MΩ
Absolute Maximum AC Voltage Measurement 1000V ac
Absolute Maximum Temperature Measurement +1090°C
Absolute Maximum Capacitance Measurement 9.999F
Functions Measured AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
True RMS Yes
Maximum Frequency 20kHz
Model Number p 83
AC Current Measurement Resolution 0.1µA
DC Current Measurement Resolution 0.1µA
Resistance Measurement Resolution 100mΩ
DC Voltage Measurement Resolution 0.1mV dc
AC Voltage Measurement Resolution 0.1mV ac
Capacitance Measurement Resolution 10nF
Temperature Measurement Resolution 0.1°C
Best DC Voltage Accuracy ±0.1% + 1 Digit
Maximum Operating Temperature +55°C
Best AC Current Accuracy ±1.2% + 2 Digits
Best AC Voltage Accuracy ±1% + 4 Digits
Height 31mm
Weight 355g
Battery Life 400 h
Width 86mm
Battery Type 9V
Safety Category Level CAT III, CAT IV
Best Capacitance Measurement Accuracy ±1% + 2 Digits
Best Resistance Measurement Accuracy ±1% + 3 Digits
Safety Category Voltage 664 V, 1000 V
Length 186mm
Best DC Current Accuracy ±0.4% + 2 Digits
Best Temperature Measurement Accuracy ±1% + 1 °C
Minimum Operating Temperature -20°C
Dimensions 186 x 86 x 31mm
